7213B.TVP FAG

Single row angular contact ball bearing

Stock
not in stock
Brand FAG
Article number 7213B.TVP FAG
Inside diameter 65mm
Outside diameter 120mm
Width 23mm
Product description

The 7213B.TVP FAG is a single row angular contact bearing. These bearings have solid inner- and outer rings. They owe their name to the contact angle that is created as the raceways of the inner and outer rings are offset from each other along the bearing axis. The bearing rings have one high and one low shoulder. Thanks to the low shoulder, a large number of balls can be incorporated in the bearing. Single row angular contact bearings can support high radial forces and axial forces in one direction. The greater the contact angle, the greater the axial load capacity of the bearing.

Help with this product

Downloads and links

Similar to: 7213B.TVP FAG

Product
Dimensions/Properties
Stock
Price ex VAT
7213-B-XL-TVP FAG
7213-B-XL-TVP FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)
55,27 ex VAT
  • Inside diameter 65mm
  • Outside diameter 120mm
  • Width 23mm
7213-B-XL-TVP FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)

4 pcs
55,27 ex VAT
7213BEP SKF
7213BEP SKF
Guaranteed same day shipment on orders placed before 18:00h (CET)
55,96 ex VAT
  • Inside diameter 65mm
  • Outside diameter 120mm
  • Width 23mm
7213BEP SKF
Guaranteed same day shipment on orders placed before 18:00h (CET)

14 pcs
55,96 ex VAT
7213BETN RHP
7213BETN RHP
Guaranteed same day shipment on orders placed before 18:00h (CET)
43,30 ex VAT
  • Inside diameter 65mm
  • Outside diameter 120mm
  • Width 23mm
7213BETN RHP
Guaranteed same day shipment on orders placed before 18:00h (CET)

5 pcs
43,30 ex VAT
7213BA SNR
7213BA SNR
Guaranteed same day shipment on orders placed before 18:00h (CET)
43,90 ex VAT
  • Inside diameter 65mm
  • Outside diameter 120mm
  • Width 23mm
7213BA SNR
Guaranteed same day shipment on orders placed before 18:00h (CET)

2 pcs
43,90 ex VAT
7213BEAT85 NSK
7213BEAT85 NSK
Guaranteed same day shipment on orders placed before 18:00h (CET)
41,36 ex VAT
  • Inside diameter 65mm
  • Outside diameter 120mm
  • Width 23mm
7213BEAT85 NSK
Guaranteed same day shipment on orders placed before 18:00h (CET)

9 pcs
41,36 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 65
  2. Outer (D) MM 120
  3. Width (B) MM 23
  4. Inner (d) Inch 2.5591
  5. Outer (D) Inch 4.7244
  6. Width (B) Inch 0.9055

Suffix description

  1. B 40° Contact Angle
  2. TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number 7213B.TVP FAG
  4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 1.085

Product Properties

  1. Seal No Seal
  2. Cage Type P - Plastic Molded Cage
  3. Precision Standard Precision
  4. Contact Angle 40 degrees
  5. Pairing No pairing
  6. Axial Internal Clearance / Preload No Preload
  7. Lubrication Standard Lubrication
