7212C G1 U J84 SNR

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 110
3. Width (B) MM 22
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 4.3307
6. Width (B) Inch 0.8661

Suffix description

1. C 15° Contact Angle
2. G1 Laminated Phenolic Cage Centered On Outer Ring
3. U Universal Single Bearing
4. J84 Dimensional & Running Accuracy To Iso Tolerance Class 4 (More Accurate Than P5)-Abec7,
5. 8 Medium Preload

Technical details

1. Availability 3 pcs
2. Brand SNR
3. Item number 7212C G1 U J84 SNR
4. Also known as 7212CDGB/P4A
   7212CT3UMP4

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.8

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GB - Medium Preload
7. Lubrication Standard Lubrication
