7210HG1UJ74 SNR

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 90
3. Width (B) MM 20
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 3.5433
6. Width (B) Inch 0.7874

Suffix description

1. H 25° Contact Angle
2. G1 Laminated Phenolic Cage Centered On Outer Ring
3. U Universal Single Bearing
4. J74 Dimensional & Running Accuracy To Iso Tolerance Class 4 (More Accurate Than P5)-Abec7,
5. 7 Light Preload

Technical details

1. Availability 0 pcs
2. Brand SNR
3. Item number 7210HG1UJ74 SNR
4. Also known as 7210ACDGA/P4A
   7210E T P2H UL
   S6210E TA ABEC7 UL

5. EAN 3413520176181
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.46

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
