7207WN Fafnir

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 72
3. Width (B) MM 17
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.6693

Suffix description

1. WN Sizes 7201K Through 7203WN Have A 20° Contact Angle And A Nylon Cage. Sizes 7204WN through 7218WN have a 40° Contact Angle And A One-Piece, Ball Piloted, Pressed Brass Cage. Larger Sizes 7219WN Through 7230WN Have A 40° Contact Angle And A One-Piece, Outer Ring Piloted High-Strength Machined Bronze Cage. Ball Bearing, Angular Contact, Super Precision, Low Shoulder On Both Rings

Technical details

1. Availability 0 pcs
2. Brand Fafnir
3. Item number 7207WN Fafnir
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.304

Product Properties

1. Seal No Seal
2. Cage Type M - Brass Cage
3. Precision Standard Precision
4. Contact Angle 40 degrees
5. Pairing No pairing
6. Axial Internal Clearance / Preload CB - Normal Axial Clearance
7. Lubrication Standard Lubrication
