7206C G1 U J74 SNR

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 62
3. Width (B) MM 16
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.6299

Suffix description

1. C 15° Contact Angle
2. G1 Laminated Phenolic Cage Centered On Outer Ring
3. U Universal Single Bearing
4. J74 Dimensional & Running Accuracy To Iso Tolerance Class 4 (More Accurate Than P5)-Abec7,
5. 7 Light Preload

Technical details

1. Availability 2 pcs
2. Brand SNR
3. Item number 7206C G1 U J74 SNR
4. Also known as 7206CDGA/P4A
   B7206-C-T-P4S-UL

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.19

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
