7205BEGAP SKF

Single row angular contact ball bearing in GA design

Stock
36 pcs in stock and ready for shipment
Brand SKF
Article number 7205BEGAP SKF
Inside diameter 25mm
Outside diameter 52mm
Width 15mm
Product description

The 7205BEGAP SKF is a single row angular contact bearing. These bearings have solid inner- and outer rings. They owe their name to the contact angle that is created as the raceways of the inner and outer rings are offset from each other along the bearing axis. The bearing rings have one high and one low shoulder. Thanks to the low shoulder, a large number of balls can be incorporated in the bearing. Single row angular contact bearings can support high radial forces and axial forces in one direction. The greater the contact angle, the greater the axial load capacity of the bearing.

The 7205BEGAP SKF is suitable for universal matching. Bearings for universal matching can be assembled directly beside each other various arrangements. No shims or other spacers are required to obtain the predetermined clearance or preload and/or even load distribution. Paired mounting is used if the load carrying capacity of a single bearing is insufficient, or if there are combined or axial loads in both directions. When using a GA bearing set in X- or O- arrangement, a light preload (standard) is present in unassembled condition.

Read more Show less
Help with this product

Similar to: 7205BEGAP SKF

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 52
  3. Width (B) MM 15
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 2.0472
  6. Width (B) Inch 0.5906

Suffix description

  1. BE Single Row Angular Contact Ball Bearing With A 40° Contact Angle And Optimized Internal Design
  2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
  3. P Injection Moulded Window-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered

Technical details

  1. Availability 36 pcs
  2. Brand SKF
  3. Item number 7205BEGAP SKF
  4. EAN 7316576632679
  5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 0.126

Product Properties

  1. Seal No Seal
  2. Cage Type P - Plastic Molded Cage
  3. Precision Standard Precision
  4. Contact Angle 40 degrees
  5. Pairing No pairing
  6. Axial Internal Clearance / Preload GA - Light Preload
  7. Lubrication Standard Lubrication
