Name: 7202CD/P4ADGA SKF
Brand: SKF

7202CD/P4ADGA SKF

The 7202CD/P4ADGA SKF is a single row angular contact ball bearing with a hard fiber cage and no seal.

Stock

not in stock

Brand

SKF

Article number

7202CD/P4ADGA SKF

Inside diameter

15mm

Outside diameter

35mm

Width

22mm

Product specifications

Availability 0 pcs
Brand SKF
Item number 7202CD/P4ADGA SKF
Technical details (CD/P4ADGA) CD=15° Contact Angle. P4A=(P4S-FAG)=(MMV-FAF)=Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4. DGA=(Segment Ax. Int. Cl/Pr, Code DL)=Two Single Row Angular Contact Ball Bearings For Universal Pairing, I.e. Paired For Mounting In A Back-To-Back, Face-To-Face Or Tandem Arrangement, Light Preload.
Also known as 7316576626470
Category Angular Contact Ball Bearing Single Row
Weight (kg) 0.0860
Manufacturer Part Number (MPN) 7202CD/P4ADGA
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4 Precision (Higher than P5)
Contact Angle 15 Degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Lubrication Standard Lubrication
