7201CDGA/P4A SKF

All dimensions

1. Inner (d) MM 12,00
2. Outer (D) MM 32,00
3. Width (B) MM 10,00
4. Inner (d) Inch 0.4724
5. Outer (D) Inch 1.2598
6. Width (B) Inch 0.3937

Suffix description

1. CD 15° Contact Angle
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 3 pcs on 26 Apr
2. Brand SKF
3. Item number 7201CDGA/P4A SKF
4. Also known as 201HCUL
   2MM201WI CR SUL
   7201 C TR SUL P3
   7201C T1 G/GL P42
   B7201C.T.P4S.UL
   E212 7CE1 UL

5. EAN 7316570831023
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.036

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
