7201ACDGA/P4A SKF

All dimensions

1. Inner (d) MM 12
2. Outer (D) MM 32
3. Width (B) MM 10
4. Inner (d) Inch 0.4724
5. Outer (D) Inch 1.2598
6. Width (B) Inch 0.3937

Suffix description

1. ACD 25° Contact Angle
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 40 pcs
2. Brand SKF
3. Item number 7201ACDGA/P4A SKF
4. Also known as 201HEUL
   3MM201WI CR SUL
   7201 A5 TR SUL P3
   7201AD T1 G/GL P42
   B7201E.T.P4S.UL
   E212 7CE3 UL

5. EAN 7316570448702
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.036

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
