71914ACDGC/P4A SKF

All dimensions

1. Inner (d) MM 70,00
2. Outer (D) MM 100,00
3. Width (B) MM 16,00

Suffix description

1. ACD 25° Contact Angle
2. GC Bearing For Paired Mounting In Random Order; When Arranged Back-To-Back Or Face-To-Face There Will Be A Heavy Preload
3. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 0 pcs
2. Brand SKF
3. Item number 71914ACDGC/P4A SKF
4. EAN 7316571346564
5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.33

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GC - Heavy Preload
7. Lubrication Standard Lubrication
