71913ACDGA/P4A SKF

All dimensions

1. Inner (d) MM 65,00
2. Outer (D) MM 90,00
3. Width (B) MM 13,00
4. Inner (d) Inch 2.5591
5. Outer (D) Inch 3.5433
6. Width (B) Inch 0.5118

Suffix description

1. ACD 25° Contact Angle
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 6 pcs on 29 Apr
2. Brand SKF
3. Item number 71913ACDGA/P4A SKF
4. Also known as 1913HEUL
   3MM9313WI CR SUL
   7913UAD T1 G/GL P42
   B71913E.T.P4S.UL
   SEB65 7CE3 UL

5. EAN 7316570722024
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.21

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
