71908CDGA/HCP4A SKF

All dimensions

1. Inner (d) MM 40,00
2. Outer (D) MM 62,00
3. Width (B) MM 12,00
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.4724

Suffix description

1. CD 15° Contact Angle
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. HC Bearing Or Bearing Components Of Ceramic
4. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 1 pc
2. Brand SKF
3. Item number 71908CDGA/HCP4A SKF
4. Also known as 2MMC9308WI CR SUL
   5S-7908UC T1 G/GL P42
   C1908HCUL
   HCB71908C.T.P4S.UL
   HCB71908-C-T-P4S-UL
   SEB40 /NS 7CE1 UL

5. EAN 7316570699050
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.114

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision H4 - Hybrid / Ceramic Balls / P4
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
