71906.E.T.P2H.DUL IBC Bearings

All dimensions

1. Inner (d) MM 30,00
2. Outer (D) MM 47,00
3. Width (B) MM 18,00
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.7087

Suffix description

1. E 25° Contact Angle
2. T Cage Of Machined Phenolic Resin, Located On Rolling Elements
3. P2H Bearing With Extreme High Running Accuracy (Abec9) And Form Tolerance (Abec7)
4. DUL Set Of 2 Universal Bearings, Light Preload

Technical details

1. Availability 8 pcs
2. Brand IBC Bearings
3. Item number 71906.E.T.P2H.DUL IBC Bearings
4. Also known as 71906ACD/P4ADGA
   7906E T DUL P4

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.096

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
7. Lubrication Standard Lubrication
