Name: 71868-MP-P5-UL FAG
Brand: FAG

71868-MP-P5-UL FAG

The 71868-MP-P5-UL FAG is a single row angular contact ball bearing with a brass cage and no seal.

Stock

not in stock

Brand

FAG

Article number

71868-MP-P5-UL FAG

Inside diameter

340,00mm

Outside diameter

420,00mm

Width

38,00mm

Product specifications

Availability 0 pcs
Brand FAG
Item number 71868-MP-P5-UL FAG
Technical details (MP-P5-UL) MP=Machined Brass Cage, Window Type, Rolling Element Riding. P5=Dimensional And Running Accuracy To ISO Tolerance Class 5. UL=(GA-SKF)=Two Single Row Angular Contact Ball Bearings For Universal Pairing, i.e. Paired For Mounting In A Back-To-Back, Face-To-Face Or Tandem Arrangement.
Category Angular Contact Ball Bearing Single Row
Description from Medias Angular contact ball bearing
Weight (kg) 11.70
Manufacturer Part Number (MPN) 71868-MP-P5-UL
Seal No Seal
Cage Type M - Brass Cage
Precision P5 Precision (Higher than P6)
Contact Angle 30 Degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
