71820CDGA/P4 SKF

All dimensions

1. Inner (d) MM 100
2. Outer (D) MM 125
3. Width (B) MM 13
4. Inner (d) Inch 3.937
5. Outer (D) Inch 4.9213
6. Width (B) Inch 0.5118

Suffix description

1. CD 15° Contact Angle
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4 Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 2 pcs
2. Brand SKF
3. Item number 71820CDGA/P4 SKF
4. Also known as B71820-C-TPA-P4-UL

5. EAN 7316574349630
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.31

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
