71811-TN INA

All dimensions

1. Inner (d) MM 55
2. Outer (D) MM 72
3. Width (B) MM 9
4. Inner (d) Inch 2.1654
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.3543
7. Width (b) mm 9

Suffix description

1. TN Polyamide Cage

Technical details

1. Availability 42 pcs
2. Brand INA
3. Item number 71811-TN INA
4. Also known as 0096210590000

5. EAN 4047643189309
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.058

Product Properties

1. Seal No Seal
2. Cage Type P - Plastic Molded Cage
3. Precision Standard Precision
4. Contact Angle 40 degrees
5. Pairing No pairing
6. Axial Internal Clearance / Preload No Preload
7. Lubrication Standard Lubrication

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 11800
2. Radial Dynamic Load Rating Cr (N) 11800
3. Limiting speed (n G) 11400
4. Reference speed (n ϑr) 5600
5. ECLASS number 23-05-08-03
6. ECLASS2 number 23-05-08-03
7. Medias description Angular contact ball bearing 718..-TVH, single row

Downloads and links

1. Download datasheet Download datasheet
2. Link to Manufacturer Link to Manufacturer
