71800ACDGA/P4 SKF

All dimensions

1. Inner (d) MM 10
2. Outer (D) MM 19
3. Width (B) MM 5
4. Inner (d) Inch 0.3937
5. Outer (D) Inch 0.748
6. Width (B) Inch 0.1969

Suffix description

1. ACD 25° Contact Angle
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4 Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7

Technical details

1. Availability 3 pcs
2. Brand SKF
3. Item number 71800ACDGA/P4 SKF
4. EAN 7316574345977
5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.005

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
