7016CD/P4ATBTA SKF

All dimensions

1. Inner (d) MM 80
2. Outer (D) MM 125
3. Width (B) MM 66
4. Inner (d) Inch 3.1496
5. Outer (D) Inch 4.9213
6. Width (B) Inch 2.5984

Suffix description

1. CD 15° Contact Angle
2. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4
3. TBTA Set Of Three Matched Single Row Deep Groove Or Angular Contact Ball Bearings <>>, Light Preload

Technical details

1. Availability 1 pc
2. Brand SKF
3. Item number 7016CD/P4ATBTA SKF
4. EAN 7316577304438
5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 2.55

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing TBT - O- and Tandem Arrangement, 3
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
