7015CD/P4AQBCB SKF

All dimensions

1. Inner (d) MM 75
2. Outer (D) MM 115
3. Width (B) MM 80
4. Inner (d) Inch 2.9528
5. Outer (D) Inch 4.5276
6. Width (B) Inch 3.1496

Suffix description

1. CD 15° Contact Angle
2. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4
3. QBCB Four Matched Single Row Deep Groove Or Angular Contact Ball Bearings Arranged Tandem - Back-To-Back <<>>, Medium Preload

Technical details

1. Availability 3 pcs
2. Brand SKF
3. Item number 7015CD/P4AQBCB SKF
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 2.48

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing QBC - O-arrangement, 4
6. Axial Internal Clearance / Preload GB - Medium Preload
7. Lubrication Standard Lubrication
