7013UCP5 NTN

All dimensions

1. Inner (d) MM 65
2. Outer (D) MM 100
3. Width (B) MM 18
4. Inner (d) Inch 2.5591
5. Outer (D) Inch 3.937
6. Width (B) Inch 0.7087

Suffix description

1. 7226C Machined High Tensile Brass Cage
2. U ULTAGE Series
3. C 15˚ Contact Angle
4. P5 Dimensional And Running Accuracy To ISO Tolerance Class 5

Technical details

1. Availability 2 pcs on Wed 22 Apr
2. Brand NTN
3. Item number 7013UCP5 NTN
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.435

Product Properties

1. Seal No Seal
2. Cage Type P - Plastic Molded Cage
3. Precision P5 Precision (Higher than P6)
4. Contact Angle 15 degrees
5. Pairing No pairing
6. Axial Internal Clearance / Preload No Preload
7. Lubrication Standard Lubrication
