7013.CV.DU.J74 SNR

All dimensions

1. Inner (d) MM 65
2. Outer (D) MM 100
3. Width (B) MM 36
4. Inner (d) Inch 2.5591
5. Outer (D) Inch 3.937
6. Width (B) Inch 1.4173

Suffix description

1. C 15° Contact Angle
2. V Laminated Phenolic Cage Centered On Outer Ring
3. DU Angular Contact Bearing Assembly With Two Bearings That Can Be Matched DB, DF Or DT
4. J74 Dimensional & Running Accuracy To Iso Tolerance Class 4 (More Accurate Than P5)-Abec7,
5. 7 Light Preload

Technical details

1. Availability 2 pcs
2. Brand SNR
3. Item number 7013.CV.DU.J74 SNR
4. Also known as 2MM9113WICRDUL
   7013C T DUL P4
   7013CD/P4ADGA
   7013CY DU GL P4
   B7013-C-T-P4S-DUL

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.84

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
7. Lubrication Standard Lubrication
