7009CD/P4ADBC SKF

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 75
3. Width (B) MM 32
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 2.9528
6. Width (B) Inch 1.2598

Suffix description

1. CD 15° Contact Angle
2. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4
3. DBC Two Single Row Deep Groove Ball Bearings (1), Single Row Angular Contact Ball Bearings (2) Or Single Row Tapered Roller Bearings Matched For Mounting In A Back-To-Back Arrangement, Heavy Preload

Technical details

1. Availability 2 pcs
2. Brand SKF
3. Item number 7009CD/P4ADBC SKF
4. Also known as B7009-C-T-P4S-DBH

5. EAN 7316574796434
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.46

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing DB - O-arrangement, 2
6. Axial Internal Clearance / Preload GC - Heavy Preload
7. Lubrication Standard Lubrication
