7003CV U J74 SNR

All dimensions

1. Inner (d) MM 17
2. Outer (D) MM 35
3. Width (B) MM 10
4. Inner (d) Inch 0.6693
5. Outer (D) Inch 1.378
6. Width (B) Inch 0.3937

Suffix description

1. C 15° Contact Angle
2. V Laminated Phenolic Cage Centered On Outer Ring
3. U Universal Single Bearing
4. J74 Dimensional & Running Accuracy To Iso Tolerance Class 4 (More Accurate Than P5)-Abec7,
5. 7 Light Preload

Technical details

1. Availability 0 pcs
2. Brand SNR
3. Item number 7003CV U J74 SNR
4. Also known as 7003CDGA/P4A
   B7003-C-T-P4S-UL
   EX17 7 CE1 UL

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.037

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
