689 2RS FSY

All dimensions

1. Inner (d) MM 9
2. Outer (D) MM 17
3. Width (B) MM 5
4. Inner (d) Inch 0.3543
5. Outer (D) Inch 0.6693
6. Width (B) Inch 0.1969

Suffix description

1. 2RS Rubber Seals At Each Side Of The Bearing

Technical details

1. Availability 912 pcs
2. Brand FSY
3. Item number 689 2RS FSY
4. Also known as 628/9-2RS1
   689-2RSR
   689DDU
   689EE
   689LLU

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.004

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
