6405-A FAG

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 80
3. Width (B) MM 21
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.8268
7. Width (b) mm 21

Suffix description

1. A Internal Design Modification

Technical details

1. Availability 114 pcs
2. Brand FAG
3. Item number 6405-A FAG
4. Also known as 0686827940000

5. EAN 4012802619980
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.543

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 19100
2. Radial Dynamic Load Rating Cr (N) 35500
3. Limiting speed (n G) 12400
4. Reference speed (n ϑr) 10100
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01

Downloads and links

1. Link to manufacturer Link to manufacturer
