6324.C4.S4 FAG

All dimensions

1. Inner (d) MM 120
2. Outer (D) MM 260
3. Width (B) MM 55
4. Inner (d) Inch 4.7244
5. Outer (D) Inch 10.2362
6. Width (B) Inch 2.1654

Suffix description

1. C4 Bearing Internal Clearance Greater Than C3
2. S4 Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +350°C (662°F)

Technical details

1. Availability 5 pcs
2. Brand FAG
3. Item number 6324.C4.S4 FAG
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 12.5

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization S4 - Temperatures up to 350 °C
9. Special Treatment No Special Treatment
