6314/C3VL2071 SKF

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 150
3. Width (B) MM 35
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 5.9055
6. Width (B) Inch 1.378

Suffix description

1. C3 Internal Clearance Larger Than Normal
2. VL2071 Electrical Insulation Of Inner Ring, Breakdown Voltage DC: 3.000 V, Ohmic Resistance: 200 MΩ

Technical details

1. Availability 0 pcs
2. Brand SKF
3. Item number 6314/C3VL2071 SKF
4. Also known as 6314/C3
   6314-C3
   6314-J20C-C3

5. EAN 7316572168585
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 2.52

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Inner Ring Resists 1000v
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
