6308M/C4VL0241 SKF

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 90
3. Width (B) MM 23
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.5433
6. Width (B) Inch 0.9055

Suffix description

1. M Machined Brass Cage, Ball Centered; Different Designs And Material Grades Are Identified By A Figure Following The M, e.g. M2
2. C4 Bearing Internal Clearance Greater Than C3
3. VL0241 Electrical Insulation Of Outer Ring, Breakdown Voltage DC: 3.000 V, Ohmic Resistance: 200 MΩ

Technical details

1. Availability 1 pc on Thu 9 Apr
2. Brand SKF
3. Item number 6308M/C4VL0241 SKF
4. Also known as 6308-M-J20AA-C4

5. EAN 7316571187877
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.765

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Breakdown Voltage 1000v
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
