6308DDU7C3EX28 ENSS NSK

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 90
3. Width (B) MM 23
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.5433
6. Width (B) Inch 0.9055

Suffix description

1. DDU7 DU, Single Contact Seal) & V-Type Viton Seal
2. C3E Internal Clearance Larger Than Normal. Electric Motor Grade
3. X28 Inner And Outer Ring Heat Stabilized To 200°C
4. ENS Lubricant, Temperature Range -40 ~ 160°C, Peak +180°C
5. S Standard Fill

Technical details

1. Availability 15 pcs
2. Brand NSK
3. Item number 6308DDU7C3EX28 ENSS NSK
4. Also known as 6308DDU7C3EX28

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.633

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS2 - Fluoro Rubber Seals / High Temperature
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Higher and Lower Temperature Grease
8. Heat Stabilization S1 - Temperatures up to 200 °C
9. Special Treatment No Special Treatment
