6306H-2RS/F Timken

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 72
3. Width (B) MM 19
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.748

Suffix description

1. H Stainless Steel
2. 2RS Rubber Seals At Each Side Of The Bearing
3. F Standard Food Safe Grease

Technical details

1. Availability 0 pcs
2. Brand Timken
3. Item number 6306H-2RS/F Timken
4. Also known as S6306-2RSR-FD

5. EAN 0013992222251
6. Category Stainless Steel Ball Bearings

Weight and Dimensions

1. Weight (kg) 0.34571

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Food Grease
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
