6304CEX3 LLU/52,5 NTN

All dimensions

1. Inner (d) MM 20
2. Outer (D) MM 52,5
3. Width (B) MM 15
4. Inner (d) Inch 0.7874
5. Outer (D) Inch 2.0669
6. Width (B) Inch 0.5906

Suffix description

1. CE Radial Clearance 'Normal Class', Low Noise
2. X3 Special Chamfer
3. LLU Rubber Seals At Each Side Of The Bearing
4. 52,5 Length Of The Outer Diameter

Technical details

1. Availability 0 pcs
2. Brand NTN
3. Item number 6304CEX3 LLU/52,5 NTN
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.144

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
