6302ZZ C3 KBF

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 42
3. Width (B) MM 13
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.6535
6. Width (B) Inch 0.5118

Suffix description

1. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 193 pcs
2. Brand KBF
3. Item number 6302ZZ C3 KBF
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.083

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
