6230-P5-C4 FAG

All dimensions

1. Inner (d) MM 150,00
2. Outer (D) MM 270,00
3. Width (B) MM 45,00
4. Inner (d) Inch 5.9055
5. Outer (D) Inch 10.6299
6. Width (B) Inch 1.7717
7. Width (b) mm 45,00

Suffix description

1. P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
2. C4 Bearing Internal Clearance Greater Than C3

Technical details

1. Availability 2 pcs
2. Brand FAG
3. Item number 6230-P5-C4 FAG
4. Also known as 0388978730040

5. EAN 4026677848789
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 10.4

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision P5 Precision (Higher than P6)
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 168000
2. Radial Dynamic Load Rating Cr (N) 187000
3. Basic static load rating, radial (C 0r) "168000.0000"
4. Limiting speed (n G) "3350.0000"
5. Reference speed (n ϑr) "3350.0000"
6. ECLASS number 23-05-08-01
7. ECLASS2 number 23-05-08-01
8. Medias description Deep groove ball bearing 62, single row, cf. DIN 625-1
