6220/C3VL0241 SKF

All dimensions

1. Inner (d) MM 100
2. Outer (D) MM 180
3. Width (B) MM 34
4. Inner (d) Inch 3.937
5. Outer (D) Inch 7.0866
6. Width (B) Inch 1.3386

Suffix description

1. C3 Internal Clearance Larger Than Normal
2. VL0241 Electrical Insulation Of Outer Ring, Breakdown Voltage DC: 3.000 V, Ohmic Resistance: 200 MΩ

Technical details

1. Availability 10 pcs
2. Brand SKF
3. Item number 6220/C3VL0241 SKF
4. Also known as 6220.C3.J20AA
   6220-C3-J20AA
   6220-J20AA-C3

5. EAN 7316571605463
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 3.3

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Breakdown Voltage 1000v
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
