6209M 2RS NIS

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 85
3. Width (B) MM 19

Suffix description

1. M Machined Brass Cage, Located On The Rolling Elements
2. 2RS Rubber Seals At Each Side Of The Bearing

Technical details

1. Availability 0 pcs
2. Brand NIS
3. Item number 6209M 2RS NIS
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.404

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
