6208-RSR FAG

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 80
3. Width (B) MM 18
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.7087
7. Width (b) mm 18

Suffix description

1. RSR One Seal, Buna-N Rubber, Radial Type

Technical details

1. Availability 106 pcs
2. Brand FAG
3. Item number 6208-RSR FAG
4. Also known as 0191033790000

5. EAN 4012801070836
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.37

Product Properties

1. Bore C - Cylindrical Bore
2. Seal RS - Rubber Seal on One Side
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 17800
2. Limiting speed (n G) 5000
3. ECLASS number 23-05-08-01
4. ECLASS2 number 23-05-08-01

Downloads and links

1. Link to manufacturer Link to manufacturer
