6208-2RSR-N FAG

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 80
3. Width (B) MM 18
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.7087
7. Width (b) mm 18

Suffix description

1. 2RSR Rubber Seals At Each Side Of The Bearing
2. N Snap Ring Groove In The Outer Ring

Technical details

1. Availability 10 pcs
2. Brand FAG
3. Item number 6208-2RSR-N FAG
4. Also known as 0191030770000

5. EAN 4012801070430
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.359

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification N - Snap Ring Groove in Outer Ring
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 17800
2. Limiting speed (n G) 5000
3. ECLASS number 23-05-08-01
4. ECLASS2 number 23-05-08-01
