6207-Z FAG

All dimensions

1. Inner (d) MM 35,00
2. Outer (D) MM 72,00
3. Width (B) MM 17,00
4. Inner (d) Inch 1.3780
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.6693
7. Width (b) mm 17,00

Suffix description

1. Z Shield Of Pressed Sheet Steel On One Side Of The Bearing

Technical details

1. Availability 8 pcs
2. Brand FAG
3. Item number 6207-Z FAG
4. Also known as 0167203500000
   6207-C-Z

5. EAN 4012801069762
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.291

Product Properties

1. Bore C - Cylindrical Bore
2. Seal Z - Steel Seal on One Side
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) "15300.0000"
2. Limiting speed (n G) "13800.0000"
3. Reference speed (n ϑr) "10400.0000"
