6207-2Z-C3-NR-K-J22C FAG

All dimensions

1. Inner (d) MM 35,00
2. Outer (D) MM 72,00
3. Width (B) MM 17,00

Suffix description

1. 2Z Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal)
2. C3 Internal Clearance Larger Than Normal
3. NR Snap Ring Groove In Bearing Outer Ring And Appropriate Snap Ring
4. K Tapered Bore, Taper 1:12
5. J22C Products Without Or With Limited Marking; Packaging Specifications; J22C Replaces Z67

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 6207-2Z-C3-NR-K-J22C FAG
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.294

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification NR - Groove and Snap Ring
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
