Name: 6206-2Z/C3HT22 SKF
Brand: SKF

6206-2Z/C3HT22 SKF

The 6206-2Z/C3HT22 SKF bearing is a single row deep groove ball bearing with a steel or standard cage, a cylindrical bore and a steel seal on two sides.

Stock

not in stock

Brand

SKF

Article number

6206-2Z/C3HT22 SKF

Inside diameter

30mm

Outside diameter

62mm

Width

16mm

Product specifications

Inside diameter 30mm
Outside diameter 62mm
Width 16mm

All dimensions

Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch -
Outer (D) Inch -
Width (B) Inch -

Technical details

Availability 0 pcs
Brand SKF
Item number 6206-2Z/C3HT22 SKF
Technical details (2Z/C3HT22) 2Z=Shield Of Pressed Sheet Steel On Both Sides Of The Bearing. C3=Internal Clearance Larger Than Normal. HT22=Grease Fill For High Temperatures (e.g. -20°C/+130°C). HT Or A Two Figure Number Following HT Identifies The Actual Grease.
Category Deep Groove Ball Bearings Single Row
Weight (kg) 0.2010
Manufacturer Part Number (MPN) 6206-2Z/C3HT22
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No Pairing
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication 2 - High Temperature Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120°C
Special Treatment No Special Treatment

Show all details
