6205-2RSR-AN02 INA

All dimensions

1. Inner (d) MM 25,00
2. Outer (D) MM 52,00
3. Width (B) MM 15,00
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.0472
6. Width (B) Inch 0.5906
7. Width (b) mm 15,00

Suffix description

1. 2RSR Rubber Seals At Each Side Of The Bearing
2. AN02 Non-Standard Seal, Resistant To Higher Temperatures, With Metal Protection Plates On The RS Seal, C3 Clearance, Greased With L077 (Klueber Barrierta L55/2)

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number 6205-2RSR-AN02 INA
4. Also known as 0009769460000
   6205-2RS1/C3
   6205-2RSR-C3

5. EAN 4054362002635
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.125

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Higher and Lower Temperature Grease
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 7800
2. Radial Dynamic Load Rating Cr (N) 14900
3. Basic static load rating, radial (C 0r) "7800.0000"
4. Limiting speed (n G) "8000.0000"
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01
7. Medias description Deep groove ball bearing 62..-2RSR, single row, cf. DIN 625-1
