6205-2RSH/HT22 SKF

All dimensions

1. Inner (d) MM 25,00
2. Outer (D) MM 52,00
3. Width (B) MM 15,00
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.0472
6. Width (B) Inch 0.5906

Suffix description

1. 2RSH RSH Contact Seal On Both Sides Of The Bearing
2. HT22 Grease Fill For High Temperatures (e.g. Range -20 ~ 130°C). HT Or A Two Figure Number Following HT Identifies The Actual Grease

Technical details

1. Availability 0 pcs
2. Brand SKF
3. Item number 6205-2RSH/HT22 SKF
4. Also known as 6205-2RS1/HT22

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.1303

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RH - High Speed Low Friction Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication 2 - High Temperature Grease
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
