6202-C-2HRS-L138 FAG

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 35
3. Width (B) MM 11
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.378
6. Width (B) Inch 0.4331
7. Width (b) mm 11

Suffix description

1. C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
2. 2HRS Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
3. L138 NS Hi-Lube Grease Lithium Soap, Temperature Range -30ºC/+130ºC

Technical details

1. Availability 10 pcs
2. Brand FAG
3. Item number 6202-C-2HRS-L138 FAG
4. Also known as 0594078590000
   0953606380000

5. EAN 4012802574920
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.0454

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RH - High Speed Low Friction Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Low Temperature Grease
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 3750
2. Limiting speed (n G) 19400

Downloads and links

1. Link to manufacturer Link to manufacturer
