6200-C-HRS FAG

All dimensions

1. Inner (d) MM 10
2. Outer (D) MM 30
3. Width (B) MM 9
4. Inner (d) Inch 0.3937
5. Outer (D) Inch 1.1811
6. Width (B) Inch 0.3543
7. Width (b) mm 9

Suffix description

1. C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
2. HRS High Speed/Low Friction Seal

Technical details

1. Availability 245 pcs
2. Brand FAG
3. Item number 6200-C-HRS FAG
4. Also known as 0623150210000
   0956624560000
   6200-HRS

5. EAN 4012802383546
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.0312

Product Properties

1. Bore C - Cylindrical Bore
2. Seal RH - High Speed Low Friction Seal on One Side
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 2600
2. Radial Dynamic Load Rating Cr (N) 6600
3. Limiting speed (n G) 26000
4. ECLASS number 23-05-08-01
5. ECLASS2 number 23-05-08-01
6. Medias description Deep groove ball bearing 62..-C-HRS, single row, cf. DIN 625-1
