61914-2RZ FAG

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 100
3. Width (B) MM 16
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 3.937
6. Width (B) Inch 0.6299
7. Width (b) mm 16

Suffix description

1. 2RZ Non-Contact Seal On Both Sides (Rubberized Gap Seal)

Technical details

1. Availability 72 pcs
2. Brand FAG
3. Item number 61914-2RZ FAG
4. Also known as 0817059480000

5. EAN 4047643336277
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.353

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RZ - Rubber and Steel Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 21200
2. Radial Dynamic Load Rating Cr (N) 25000
3. Limiting speed (n G) 8100
4. Reference speed (n ϑr) 6400
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01
7. Medias description Deep groove ball bearings 619..-2RZ, Main dimensions to DIN 625-1, non-contact radial seals on both sides
