61904-2RSR-HLC FAG

All dimensions

1. Inner (d) MM 20
2. Outer (D) MM 37
3. Width (B) MM 9
4. Inner (d) Inch 0.7874
5. Outer (D) Inch 1.4567
6. Width (B) Inch 0.3543
7. Width (b) mm 9

Suffix description

1. 2RSR Rubber Seals At Each Side Of The Bearing
2. HLC Factory Location Code, No Additional Meaning, Can Be Used As Standard

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 61904-2RSR-HLC FAG
4. Also known as 0551940100000
   61904-2RSR
   6904 2RS

5. EAN 4012802402612
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.0373

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 3680
2. Radial Dynamic Load Rating Cr (N) 6380
3. Basic static load rating, radial (C 0r) "3680.0000"
4. Limiting speed (n G) 10600
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01
7. Medias description Deep groove ball bearings 619..-2RSR, main dimensions to DIN 625-1, lip seals on both sides
