6017TCG12P4 NSK

All dimensions

1. Inner (d) MM 85
2. Outer (D) MM 130
3. Width (B) MM 22
4. Inner (d) Inch 3.3465
5. Outer (D) Inch 5.1181
6. Width (B) Inch 0.8661

Suffix description

1. T Phenolic Cage
2. CG12 Special Clearance
3. P4 Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 6017TCG12P4 NSK
4. EAN 00029176624544
5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.89

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type TB - Hard Fiber Cage
4. External Modification No External Modification
5. Radial Internal Play Special Internal Clearance
6. Precision P4 Precision (Higher than P5)
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
