6016-2ZR C3 ZVL

All dimensions

1. Inner (d) MM 80
2. Outer (D) MM 125
3. Width (B) MM 22
4. Inner (d) Inch 3.1496
5. Outer (D) Inch 4.9213
6. Width (B) Inch 0.8661

Suffix description

1. 2ZR Two Shields On Both Sides Adjacent To The Smooth Rib Of The Inner Ring
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 0 pcs
2. Brand ZVL
3. Item number 6016-2ZR C3 ZVL
4. Also known as 6016-2Z/C3
   6016-2Z-C3
   6016ZZ C3

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.85

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
