6015-2RSR-C2 FAG

All dimensions

1. Inner (d) MM 75
2. Outer (D) MM 115
3. Width (B) MM 20
4. Inner (d) Inch 2.9528
5. Outer (D) Inch 4.5276
6. Width (B) Inch 0.7874
7. Width (b) mm 20

Suffix description

1. 2RSR Rubber Seals At Each Side Of The Bearing
2. C2 Bearing Internal Clearance Smaller Than Normal

Technical details

1. Availability 20 pcs
2. Brand FAG
3. Item number 6015-2RSR-C2 FAG
4. Also known as 0167180890020

5. EAN 4012802320879
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.64

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C2 Internal Play (Less than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 33500
2. Radial Dynamic Load Rating Cr (N) 42000
3. Limiting speed (n G) 3050
4. ECLASS number 23-05-08-01
5. ECLASS2 number 23-05-08-01
6. Medias description Deep groove ball bearing 60..-2RSR, single row, cf. DIN 625-1
