6014M/C3S0 SKF

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 110
3. Width (B) MM 20
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 4.3307
6. Width (B) Inch 0.7874

Suffix description

1. M Machined Brass Cage, Ball Centered; Different Designs And Material Grades Are Identified By A Figure Following The M, e.g. M2
2. C3 Internal Clearance Larger Than Normal
3. S0 Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +150°C (302°F)

Technical details

1. Availability 1 pc
2. Brand SKF
3. Item number 6014M/C3S0 SKF
4. Also known as 6014M/C3
   6014-M-C3

5. EAN 7316570154535
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.755

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization S0 - Temperatures up to 150 °C
9. Special Treatment No Special Treatment
